MAIN |
Frequency Range
(For Sine, Square) |
0.1Hz~4MHz |
Frequency Range
(For Triangle) |
0.1Hz~1MHz |
| Frequency Resolution |
0.1Hz |
| Frequency Stability |
∮ 20 ppm |
| Frequency Accuracy |
∮ 20 ppm |
| Frequency Aging |
∮ 5 ppm / year |
| Output Function |
Sine, Square, Triangle |
| Amplitude Range |
10Vpp(into 50?load) |
| Flatness(Sinewave relative to 1kHz) |
≌∮ 0.3dB,0.1Hz°1MHz; ≌∮ 0.5dB,1MHz°4MHz; ≌∮ 2dB, 4MHz°10MHz |
| Impedance |
50?∮10? |
| Attenuator |
-20dB∮1dB⊙2 |
| DC Offset |
≌-5V°≈+5V(into 50?load) |
| Duty Control Range |
20% to 80% below 1MHz (Square wave only) |
| Duty Control Resolution |
1% |
| Display |
9 digits LED display |
SINE WAVE |
| Harmonics Distortion |
-55dBc,0.1Hz°200kHz; -40dBc,0.2MHz°4MHz; -30dBc,4MHz°10MHz
(Specification applied from MAX. to 1/10 level) |
TRIANGLE WAVE |
| Linear |
≠98?,0.1Hz°100kHz;≠95?,100kHz°1MHz |
SQUARE WAVE |
| Symmetry |
∮ 1% of period +4ns to 0.1Hz°100kHz ;Rise or Fall Time; ∝25ns at maximum output.(into 50?load) |
CMOS OUTPUT |
| Level |
4Vpp∮1Vpp°14.5Vpp∮0.5Vpp adjustable; Rise or Fall Time; ∝120ns |
TTL OUTPUT |
| Level |
≠3Vpp ; Fan Out; 20 TTL load ; Rise or Fall Time ; ∝25ns |
SWEEP OPERATION |
| Sweep/Rate |
100:1 ratio max. and adjustable |
| Sweep/Time |
0.5Sec°30Sec adjustable |
| Sweep/Mode |
Lin. / Log. switch selector |
AMPLITUDE MODULATION |
| Depth & MOD. Frequency |
0°100? ; 400Hz(INT),DC°1MHz(EXT) |
| Carrier BW |
100Hz°5MHz(-3dB) |
| EXT Sensitivity |
∝10Vpp for 100?modulation |
FREQUENCY MODULATION |
| Deviation & MOD. Frequency |
0°∮5? ; 400Hz(INT),1kHz(EXT) |
EXT Sensitivity
|
∝10Vpp for 10? modulation |
FREQUENCY COUNTER |
| Range |
5Hz°150MHz |
| Accuracy |
Time base accuracy∮1count |
| Time base |
∮20ppm(23?∮5?) after; 30 minutes warm up |
| Resolution |
The maximum resolution is 100nHz for 1Hz and 0.1Hz for 100MHz |
| Input Impedance |
1M?/150pf |
| Sensitivity |
∝35mVrms(5Hz~100MHz)
∝45mVrms(100MHz~150MHz) |
| STORE/RECALL FUNCTION |
|
10 groups of Setting memories |
| POWER SOURCE |
AC115V, 230V∮15%, 50/60Hz |
|
|
ACCESSORIES |
|
Instruction manual x 1
Power Cord x 1
GTL-101 x 2 |
| DIMENSION & WEIGHT |
107(W)⊙266(H)⊙293(D) m/m
Approx. 3.2kg |
，
